Go multithreading with go routines, channels and waitgroups: a Golang kata

← Back to list
Last updated: June 9, 2023
Image by AI on Midjourney

Table of contents

Case-study 1: Chuck Norris counting
Case-study 2: implementing the lazy init pattern
Case-study 3: implementing an analog of setInterval() from JS
Case-study 4: controlling the goroutine from outside and communicating with it
Quick facts about channels and the select statement
Exit condition starvation
Empty default case
***

# Case-study 1: Chuck Norris counting

It's a well-established fact, that Chuck Norris counted from zero to the infinity. Twice. Today I'm gonna prove it using Golang.

What I plan to achieve:

  • Make a routine that counts from 0 onwards.
  • Run that routine in threads in amount that is equal to the number of CPU cores.
  • Read the output of the threads by consuming a channel, and display that in the main process.
  • The main process should wait for all the threads to complete.
  • On pressing Ctrl+C implement graceful shutdown of the threads.
  • Have a cancellable context the threads will check on, to make sure to come to a halt when the context expires.

In order to achieve this, the following instruments of the language must be used:

  • Go routines that allow running a piece of code in a thread.
  • Channels to communicate with those threads. They work somewhat similar to the NodeJS pipes.
  • Wait groups to sync between the threads and the main process.

Cool, sounds like a plan.

I've spent some time trying to figure the solution, but here is the code eventually:

👉 📃  cmd/main.go
package main


import (
	"context"
	"fmt"
	"os"
	"os/signal"
	"runtime"
	"sync"
	"syscall"
	"time"
)


type CounterValue struct {
	ChuckID int32
	Value   int32
}


func main() {
	numCPUs := runtime.NumCPU()


	ctx, cancelCtx := context.WithCancel(context.Background())
	defer cancelCtx()


	// the data channel is used to retrieve the results produced by the other threads
	dataChannel := make(chan *CounterValue)


	signalChannel := GetSignalChan()


    // start another thread that will monitor the signalChannel
	go func() {
		// reading from the channel. this is a blocking operation
		<-signalChannel


		fmt.Println("Terminating...")


		// the context cancellation triggers the shutdown procedure
		cancelCtx()
	}()


	wg := sync.WaitGroup{}
	wg.Add(numCPUs) // add numCPUs locks to the wait group


	for i := 0; i < numCPUs; i++ {
		// fly, my friend
		go ChuckNorris(ctx, &wg, dataChannel, i, int32(i*10))
	}


	// try reading from the channel in an endless cycle. This is a blocking operation,
	// but the main thread doesn't do anything useful anyway
	for {
		select {
		case <-ctx.Done():
			break
		case msg, open := <-dataChannel:
			if !open {
				break
			}
			fmt.Printf("%d counts %d\n", msg.ChuckID, msg.Value)
		}
	}


	// wait until all threads gracefully shut down
	wg.Wait()


	// only now we close the data channel, to avoid panics-on-closed-channel-read in the Chucks
	close(dataChannel)
}


func ChuckNorris(ctx context.Context, wg *sync.WaitGroup, dataChannel chan<- *CounterValue, id int32, increment int32) {
	defer wg.Done() // release 1 lock from the wait group


	counter := int32(0)
	sent := true
	for {
		// check if the context wasn't cancelled
		select {
		case <-ctx.Done():
			fmt.Printf("Chuck #%d has left the building\n", id)
			return
		default:
		}


		// imitate some heavy duty
		time.Sleep(2 * time.Second)


		// do actual work only if the previous one was sent
		if sent {
			counter += increment
		}


		// try sending to the channel
		select {
		case dataChannel <- &CounterValue{
			ChuckID: id,
			Value:   counter,
		}:
			sent = true
		default:
			sent = false
		}
	}
}


// GetSignalChan returns a channel that informs about pressing Ctrl+C
func GetSignalChan() chan os.Signal {
	signalChannel := make(chan os.Signal, 1)
	signal.Notify(signalChannel,
		syscall.SIGHUP,
		syscall.SIGINT,
		syscall.SIGTERM,
		syscall.SIGQUIT)


	return signalChannel
}
📃 Copy
The code is licensed under the MIT license

Here is the breakdown of what the code does:

  • It gets the amount of CPU cores.
  • Then it creates a cancellable context.
  • Then it creates an unbuffered data channel, and a signal channel, and starts a go routine that listens to the termination events. When the termination event is given, that go routine cancels the context and closes the data channel.
  • Then it defines a wait group and adds N locks, where N is the amount of CPU cores.
  • After that it launches N go routines that count.
  • And after that, the main process tries to read from the data channel in an endless cycle. This is a blocking operation, but that's fine, since the main thread does not need to do pretty much anything useful after.
  • When the data channel is finally closed, the main process moves on and waits until all the counter threads exit.

Each go routine that counts does the following:

  • It counts non-stop, trying to write the result to the data channel.
  • It checks the context on every iteration. If the context was cancelled, the routine removes one lock from the wait group and exits.

I know, it looks complicated and a bit difficult to wrap the head around, but eventually it turns to be quite straight forward.

I need keep in mind the following for the future:

  • I always need to use make() when creating channels. This will not work: var channel chan int32, but due to some funny reason it won't panic either. It may have something to do with the fact, that channels are "special, reference-like" objects.

# Case-study 2: implementing the lazy init pattern

Lazy init is a solid pattern, but when it comes to multi-threading it should be implemented in the right way, to prevent duplicate initialization on concurrent requests. Consider the following code:

package main


import (
	"fmt"
	"sync"
)


type Service struct {
	subSvc    *SubService
	initMutex sync.Mutex
}


func (s *Service) getSubService() (*SubService, error) {
	if s.subSvc == nil {
		s.initMutex.Lock()
		defer s.initMutex.Unlock()


        if s.subSvc == nil {
            fmt.Println("Init!")
            s.subSvc = &SubService{}
        }
	}


	return s.subSvc, nil
}


func (s *Service) GetToken() (string, error) {
	svc, err := s.getSubService()
	if err != nil {
		return "", err
	}


	return svc.GetToken(), nil
}


type SubService struct {
}


func (ss *SubService) GetToken() string {
	return "Hello there"
}


func main() {
	serv := &Service{}


	var wg sync.WaitGroup
	wg.Add(3)


	concurrentCall := func() {
		token, err := serv.GetToken()
		if err != nil {
			panic(err)
		}


		fmt.Printf("Token: %s\n", token)
		wg.Done()
	}


	go concurrentCall()
	go concurrentCall()
	go concurrentCall()


	wg.Wait()
}
📃 Copy
The code is licensed under the MIT license

Here, despite the fact that the concurrentCall() is done three times simultaneously, the InitSubService() function will be initialised exactly once, thanks to the mutex.

# Case-study 3: implementing an analog of setInterval() from JS

There is a way to implement an analog of setInterval() using go routines and channels without sleep(). Here is how it is done.

package main


import (
	"context"
	"fmt"
	"sync"
	"time"
)


const Interval = time.Second * 3


func main() {
	ctx := context.Background()
	ctx, cancelCtx := context.WithCancel(ctx)
	defer cancelCtx()


	go func() {
		for {
			select {
			case <-ctx.Done():
				fmt.Printf("context cancelled\n")
				return
			case <-time.After(Interval):
				err := doStuff()
				if err != nil {
					cancelCtx()
					return
				}
				fmt.Printf("tick!\n")
			}
		}
	}()


	wg := sync.WaitGroup{}
	wg.Add(1)
	wg.Wait()
}


func doStuff() error {
	return nil
}
📃 Copy
The code is licensed under the MIT license

# Case-study 4: controlling the goroutine from outside and communicating with it

You normally want to pass a context to a goroutine to be able to interrupt its execution, and also communicate with the goroutine using channels.

package main


import (
	"context"
	"fmt"
	"sync"
	"time"
)


func main() {
	ctx, cancelCtx := context.WithTimeout(context.Background(), time.Duration(time.Millisecond*80))
	defer cancelCtx()


	wg := sync.WaitGroup{}
	wg.Add(1)


	commChannel := make(chan int)


	go getEm(ctx, &wg, commChannel)


	commChannel <- 1
	commChannel <- 2
	commChannel <- 3
	close(commChannel)


	wg.Wait()
}


func getEm(ctx context.Context, wg *sync.WaitGroup, commChannel chan int) {
	defer wg.Done()


	for {
		select {
		case <- ctx.Done():
			fmt.Printf("context cancelled\n")
			return
		case number, ok := <- commChannel:
			if !ok {
				// channel is closed
				return
			}


			fmt.Printf("number is %d!\n", number)


			select {
			case <- ctx.Done():
				fmt.Printf("context cancelled\n")
				return
			default:
			}
		}
	}
}
📃 Copy
The code is licensed under the MIT license

What is important here:

  • The commChannel is closed after the last message is sent. If this is not done, the goroutine will never exit and this will lead to a deadlock.
  • The ctx is passed to the goroutine, and if it timeouts, the goroutine exits.
  • The comma ok idiom is used to check if the channel is closed. Without it, the goroutine will never know that the channel is closed, thus the case number := <- commChannel: will always trigger first, and the for loop will continue indefinitely. Reading from a closed channel is always successful and returns the zero value of the channel type.

# Quick facts about channels and the select statement

  • Reading from an open unbuffered or empty buffered channel is always blocking.
  • Writing to an open unbuffered or full buffered channel is always blocking.
  • Reading from a closed channel is always non-blocking, successful and returns a zero value of the channel type.
  • Writing to a closed channel panics.
  • Closing a closed or nil (unitialized) channel panics (use sync.Once to close a channel only once).
  • Always use the comma ok idiom inside a select statement to check if the channel is closed, to be on a safe side.
  • The select statement is undeterministic, so the order of the cases isn't guaranteed.
  • The select statement chooses one ready case pseudo-randomly when multiple cases are ready, but doesn't guarantee equal probability, so it may lead to condition starvation.
  • The select statement becomes non-blocking when there is a default case.

# Exit condition starvation

Since the select statement is undeterministic, it can lead to a situation when one of the cases is never triggered. This is called "condition starvation", and can lead to a go routine becoming unresponsive. To avoid this, a nested select statement is used:

func someWorker(ctx context.Context, aVeryBusyChannel chan int) {
	for {
		select {
		case <- ctx.Done():
			return
		case val, ok := <- aVeryBusyChannel:
			if !ok {
				return
			}
			doSomeHeavyWork(val)


			select {
				case <- ctx.Done(): // always check
				return
				default: // move on
			}
		}
	}
}
📃 Copy
The code is licensed under the MIT license

# Empty default case

An empty default case in a select statement inside an endless for loop is a CPU trasher:

for {
    select {
    case data := <-ch:
        // process data
    case <-ctx.Done():
        return
    default:
        // Empty default - if ch and ctx aren't ready,
        // this will spin in a tight loop consuming CPU!
    }
}
📃 Copy
The code is licensed under the MIT license

Don't use the default case in a select statement inside an endless for loop.

Avoid adding a delay in the default case either (in attempt to reduce CPU usage), it's a bad pattern and can lead to delayed exit of the go routine. Having such a delay usually signals that you don't need the default case at all.

***

That's all, folks!

As usual, the code of the kata is available here. Have fun!
