Posted on 13.07.2023
Image by AI on Midjourney
Refill!

In this article I will post kubectl commands and Kubernetes tricks I use as part of my daily routine. I don't remember things by heart, but I am also sick and tired of googling each time. So here is the list of absolute must-know CLI commands that is used to operate a cluster on daily basis.

Aliases

The kubectl CLI command name is objectively challenging to spell. The letter combination is not handy and can't be easily typed in. So, I define an alias:

👉 📃  ~/.bash_profile
$
alias k="kubectl"
The code is licensed under the MIT license

Contexts

The next thing I may want to do is to see the list of contexts. Each context represents a separate cluster. To see the list of contexts:

$
k config get-contexts
The code is licensed under the MIT license

To switch to a specific context:

$
k config use-context <CONTEXT_NAME>
The code is licensed under the MIT license

To delete a context no longer needed:

$
k config delete-context <CONTEXT_NAME>
The code is licensed under the MIT license

If find it useful to add some aliasing for the first two commands:

👉 📃  ~/.bash_profile
$
alias kctx="k config get-contexts"
alias kuctx="k config use-context"
The code is licensed under the MIT license

Adding contexts

The way to add new contexts depends on the kind of cloud provider used. For GCP the method is the following:

  1. Activate your project:

    $
    gcloud config set project <PROJECT_ID>
    The code is licensed under the MIT license
  2. Knowing the cluster name and the zone it operates in, add the context:

    $
    gcloud container clusters get-credentials <CLUSTER_NAME> --zone <CLUSTER_ZONE>
    The code is licensed under the MIT license

Namespaces

To see the list of all namespaces on a cluster:

$
k get namespace
The code is licensed under the MIT license

As most of the time I work with just one application, it makes sense narrow the scope to just one particular namespace:

👉 📃  ~/.bash_profile
$
alias kn="k -n <NAMESPACE_OF_MY_APP>"
The code is licensed under the MIT license

Seeing a list of pods

To see the list of pods, there is a command:

$
kn get pod
The code is licensed under the MIT license

To see the list of pods and containers running inside each of them, here is a snippet:

$
kn get pods -o jsonpath='{range .items[]}{"\n"}{.metadata.name}{"\t"}{range .spec.containers[]}{.name}{"=>"}{.image}{"\t"}{end}{end}'|sort|column -t
The code is licensed under the MIT license

To get a list of containers and images they are spinning, here is another snippet:

$
kn get pods -o json | jq '.items[] | { "name": .metadata.labels.name, "country": .metadata.labels.country, "image": .status.containerStatuses[].imageID }'
The code is licensed under the MIT license

Note, that I select imageID, not image, because the sha digest is much more valuable than just an image name + a tag.

Getting pod name by job name

Sometimes it is needed to read the job log to see why it failed. Every job is backed by a temporary pod. Knowing the pod name, we can get to the logs and hopefully understand the reason.

To get the pod name that backs the job, use:

$
kn get pods --selector=job-name=<JOB_NAME>
The code is licensed under the MIT license

Getting info about a specific pod

There is a way to see the detailed information about a pod: labels, a list of containers, etc.

$
kn get pods <POD_NAME> -o json
The code is licensed under the MIT license

Getting a list of containers in a pod

$
kn get pods <POD_NAME> -o jsonpath='{.spec.containers[*].name}'
The code is licensed under the MIT license

Reading container's logs

To see the logs there is a command:

$
kn logs <POD_NAME> -c <CONTAINER_NAME>
The code is licensed under the MIT license

If you don't specify the -c parameter, it will print logs of the default container of the pod (this is probably not what you want, so get the list of containers on the pod first).

If there is a job you are running inside of the cluster, and you need real time log output, there is the "-f" option:

$
kn logs -f <POD_NAME> -c <CONTAINER_NAME>
The code is licensed under the MIT license

Exec into a container

Exec into a container may be last resort. But, anyway, there is how it is done:

$
kn exec -it <POD_NAME> -c <CONTAINER_NAME> -- sh
The code is licensed under the MIT license

Most of the time I use it when I need to check the env vars with printenv.

Restarting a pod

Sometimes I want a pod restarted, in case if it misbehaves. I scale it down to zero and then up again.

$
kn scale deploy <POD_NAME> --replicas=0
kn scale deploy <POD_NAME> --replicas=<ORIGINAL_NUM_OF_REPLICAS>
The code is licensed under the MIT license

Getting K8s events

If a deployment is reported to be scaled up, but nothing shows up, it's a good case for reading the event log of the K8s itself:

$
kn get events
The code is licensed under the MIT license

Getting info about jobs

If I have a regular job, or a cron job, I may want to see how it is doing. Assuming that I have the jq tool installed, I can then type:

$
kn get job -l <LABEL_NAME>=<LABEL_VALUE> -o json | jq -r '.items[] | select(.status.succeeded) | .status.completionTime' | sort -r | head -n 1
The code is licensed under the MIT license

The -l command is a selector by label. It accepts a label name and label value to filter the list of jobs against.

Injecting an env variable

Sometimes an environment variable must be injected into a working pod, without changing the terraform files or redeploying. For example, if there is a need to temporary increase the logging level from "warn" to "debug". This is how it's done:

$
kn set env deployment/<DEPLOYMENT_NAME> <ENV_VAR_NAME>=<VALUE>
The code is licensed under the MIT license

This command will patch the deployment and do the rolling update.

Connecting to a container from outside

Most of the time, there is no connectivity between a container and an outer world, because a port may not be exposed via an ingress. If debugging is needed, it is possible to do port forwarding to a local machine.

$
kn port-forward pod/<POD_NAME> <LOCAL_PORT>:<POD_PORT>
The code is licensed under the MIT license

After running this command, the pod becomes available through localhost:<LOCAL_PORT>.

Creating a temporary container and SSH into it

Sometimes, just for the sake of debugging, I may want to create a new container to check/debug something. I can then pick an image, run it and SSH into it. After the work is done, the container gets removed.

$
kn run -i --tty my-test-container --image=ubuntu --restart=Never --rm -- /bin/bash
The code is licensed under the MIT license

Creating resources

If a cluster resource was deleted by mistake, and you have a yaml file describing it (most likely in the infra repository), no need to worry, as it can be easily restored using the following command:

$
kn apply -f resources/my-missing-resource.yaml
The code is licensed under the MIT license

Applying the aliases

Don't forget to apply those:

$
source ~/.bash_profile
The code is licensed under the MIT license

As usual, this is a work in progress article. I will add more commands later as soon as I have them!
